Fuel Box

The Fuel Box is designed to receive fuel from hopper-bottom storage units such as the Midi Hopper and the Texsilo line. It acts as the interface between the storage system and the extraction units, ensuring a controlled and reliable transition of biomass into the transport circuit.

The box can be paired with various extraction systems, including the double pipe inlet (art. AP3400.00.01) and the Vacu Matic Free (art. AP3400.00.09). In the specific case of Vacu Matic Free, the Fuel Box can accommodate up to two extraction systems simultaneously, enabling the feeding of two different installations at the same time.

Constructed in galvanised steel sheet, the unit offers strong structural durability and long-term resistance to fuel abrasion. It is equipped with an inspection door that allows easy access for visual checks and routine maintenance. Installation is straightforward and requires no special tools, making the Fuel Box an efficient, high-performing addition to any biomass storage system.

Features

• Exclusive for hopper-bottom storage tanks: Designed to work specifically with Midi Hopper and Texsilo systems.
• Houses up to two extraction systems: Ideal for installations requiring dual simultaneous feed.
• Sturdy and easy to install: Galvanised steel construction with quick mounting.
• Inspection door included: Facilitates cleaning and maintenance.
